High Voltage
| 12867-06-W | MULTIPIN CONNECTOR | 7 | Weld | 12kV | 13 | Yes |
0 in stock
$686.40
|
Enquire | |
| 12867-07-CF | MULTIPIN CONNECTOR | 7 | NW35CF | 12kV | 13 | Yes |
6 in stock
$739.20
|
||
| 17159-02-KF | MULTIPIN CONNECTOR | 7 | NW40KF | 12kV | 13 | Yes |
0 in stock
$718.08
|
Enquire | |
| 12475-03-W | MULTIPIN CONNECTOR | 2 | Weld | 12kV | 13 | Yes |
0 in stock
$594.00
|
Enquire | |
| 12475-04-W | MULTIPIN CONNECTOR | 4 | Weld | 12kV | 13 | Yes |
0 in stock
$620.40
|
Enquire | |
| 17157-02-KF | MULTIPIN CONNECTOR | 2 | NW40KF | 12kV | 13 | Yes |
in stock
|
Enquire | |
| 12476-03-CF | MULTIPIN CONNECTOR | 2 | NW35CF | 12kV | 13 | Yes |
in stock
|
Enquire | |
| 12476-04-CF | MULTIPIN CONNECTOR | 4 | NW35CF | 12kV | 13 | Yes |
in stock
|
Enquire | |
| 17158-02-KF | MULTIPIN CONNECTOR | 4 | NW40KF | 12kV | 13 | Yes |
in stock
|
Enquire |
Specifications
Shell:
304 Stainless steel
Pins:
Molybdenum (Nickel plated)
Insulation:
Alumina ceramic
Magnetic materials:
Yes
Voltage Rating:
12kV DC
Current Rating:
13 Amps per pin
Temperature Range:
-269º C to 450º C, ISO KF -25º C to 205º C
Pressure @ 20ºC:
2 Pin: 400 PSIG (28 Bar)
4 Pin: 300 PSIG (20 Bar)
7 Pin - 200 PSIG (14 Bar)
Leak Rate:
<1x10-10 atm-cc/sec (He)
