| 19485-01-CF | VIEWPORT EXTENDED RANGE | .50 (13) | Zinc Selenide | NW16CF | 10.6 Micron | 10.6 Micron optimized | 98 | Yes |
in stock
|
Enquire | |
| 19485-02-CF | VIEWPORT EXTENDED RANGE | .50 (13) | Cleartran | NW16CF | 10.6 Micron | 10.6 Micron optimized | 98 | Yes |
in stock
|
Enquire | |
| 19485-03-CF | VIEWPORT EXTENDED RANGE | .50 (13) | Magnesium Fluoride | NW16CF | No | 0.12 to 7 Microns | Yes |
in stock
|
Enquire | ||
| 19485-04-CF | VIEWPORT EXTENDED RANGE | .50 (13) | Calcium Fluoride | NW16CF | No | 0.12 to 9 Microns | Yes |
in stock
|
Enquire | ||
| 19485-05-CF | VIEWPORT EXTENDED RANGE | .50 (13) | Zinc Selenide | NW16CF | No | 0.55 to 18 Microns | Yes |
in stock
|
Enquire | ||
| 19163-01-CF | VIEWPORT EXTENDED RANGE | .50 (13) | Zinc Selenide | NW35CF | 10.6 Micron | 10.6 Micron optimized | 98 | Yes |
in stock
|
Enquire | |
| 19163-02-CF | VIEWPORT EXTENDED RANGE | .50 (13) | Cleartran | NW35CF | 10.6 Micron | 10.6 Micron optimized | 98 | Yes |
in stock
|
Enquire | |
| 19163-03-CF | VIEWPORT EXTENDED RANGE | .50 (13) | Magnesium Fluoride | NW35CF | No | 0.12 to 7 Microns | Yes |
in stock
|
Enquire | ||
| 19163-04-CF | VIEWPORT EXTENDED RANGE | .50 (13) | Calcium Fluoride | NW35CF | No | 0.12 to 9 Microns | Yes |
in stock
|
Enquire | ||
| 19163-05-CF | VIEWPORT EXTENDED RANGE | .50 (13) | Zinc Selenide | NW35CF | No | 0.55 to 18 Microns | Yes |
in stock
|
Enquire |
Specifications
Flange:
304 Stainless steel
O-ring:
Viton®
Optics:
See table
Magnetic materials:
Yes
Transmission Range:
0.12 to 20 Microns
Temperature Range:
-8º C to 204º C
Leak Rate:
<1x10-10 atm-cc/sec (He)
